Suntan Product Selection Guide
| Product Selection Guide |
|
Tantalum Capacitors
|
Suntan is a Hong Kong based manufacturer of Tantalum Capacitor. Range includes Dipped Tantalum Capacitors, Chip Tantalum Capacitors, SMD Tantalum Capacitors etc. Please refer to below product list of Tantalum Capacitors.
|
|
|
Dipped Tantalum Capacitor Features
Suntan produce Dipped tantalum capacitor of Hi-quality and competitive price for over 30 years. This product range which features high stable performance, lower current leakage and dissipation factor, stable frequency & temperature and long life. It meets and exceeds the requirements of IEC Specification 384 --15 -- 3, IECQ Specification QC300201/US0003 and Technical Specification SJ/T10856--96. Application: military and civil applications include TV sets, camcorders, computers, program-controlled electronic telephone, switching systems, telephones, instruments and meters.
 |
Download PDF for full specifications for TS19 Dipped Tantalum Capacitor |
|
|
|
Suntan LOW ESR Tantalum Capacitor
TS20L series are LOW ESR Chip Tantalum Capacitors. This type of capacitor is available in 6 different sizes ( S case, A case, B Case, C case, D case, E Case ).
- Temperature Range: -55°C~+125°C (>80°C with rated volted darating)
- Laser-marked Case
- Capacitance tolerance: +/-20%; +/-10% (for special order)
- DC leakage at 25°C:1o<=0.01 Cr or 0.5Ma (Whichever is greater)
The above features make this range ideal for SMT applications including telecommunication, computer, camcorder and mobile phone set.
|
Download PDF for full specifications for TS20 Chip Tantalum Capacitor - SMD |
|
Download PDF for full specifications for TS20L Chip Tantalum Capacitor Low ESR |
|
|
|
|
Ceramic Capacitors
|
|
Suntan also manufacture a range of Ceramic Capacitors. Including High Voltage Ceramic Capacitors, Multilayer Ceramic Capacitors, Ceramic Disc Capacitors, Mini Type Ceramic Capacitors etc. Please refer to below product list of Ceramic Capacitors.
|
|
|
Ceramic Capacitors
TS20L series are LOW ESR Chip Tantalum Capacitors. This type of capacitor is available in 6 different sizes ( S case, A case, B Case, C case, D case, E Case )
Download PDFs for full specifications
|
TS15 Ceramic Disc Capacitor |
|
TS16 High Voltage Ceramic Capacitor |
|
TS16L Low D.F., Disc (A And B Series) |
|
TS16M Mini Type Ceramic Capacitor |
|
TS17 Multilayer (mono) Axial & Radial |
|
TS18 Multilayer Ceramic Capacitor - SMD |
|
TS18H High Voltage Multilayer Ceramic Capacitor - SMD |
|
Capacitance Change VS Temperature Characteristic; Voltage; Frequency |
Multilayer Ceramic Capacitor
Suntan TS17A Axial Multilayer Ceramic Capacitor can be made 50VDC and 100VDC, from 100pF to 1uF. The leads can be bended for mounting purpose. They have a wide range of applications in computer, data processor, telecommunication, industrial control, and instrumentation equipments, etc. They are manufactured with a superior moisture and shock resistant epoxy coating, can be supplied in both bulk or tape and reel package for automatic insertion in printed circuit board.
Suntan TS18H Series (SMT Types) are available for high voltage applications .... 500V, 1KV, 2KV, 3KV, 4KV & 5KV rating.
|
|
|
 |
|
|
|
|
|
|
|
Trimming Potentiometers
|
|
Suntan manufacturer a wide range of Trimming Potentiometers including SMD Trimming Potentiometers, Rectangular Trimming Potentiometers, Wirewould Trimming Potentiomers, Phenolic Trimming Potentiometers and 5, 6, 7, 8, 9 terminal Trimming Potentiometers etc. Please refer to below product list of Trimming Potentiometers.
|
|
|
Trimming Potentiometers
Download PDFs for full specifications
|
TSR-3006 Rectangular |
|
TSR-3323 7 Terminal Square |
|
TSR-3296 5 Terminal Square |
|
TSR-3361 1/4 Square SMD |
|
TSR-3362 9 Terminal Square |
|
TSR-3386 8 Terminal Square |
|
TSR-3329 Circularity |
|
TSR-3266 5 Terminal Square |
Trimming Potentiometer - 3386 series with knob
Now Suntan TSR-3386 all sub-series are available with knob now for finger adjustment. When you place order, just need add suffix letter 'T' for new order code. This single turn square trimming potentiometer is cemet, sealed for industrial use, it is with many terminal types, such as TSR-3386B, 3386C, 3386H, 3386J, 3386S, 3386W, 3386T, 3386U, 3386Y, 3386G, 3386V, 3386F, 3386K, 3386M, 3386R and TSR-3386X. The resistance tolerance for this series is 5% or 10%, rotational life is 200 cycles. Standard package is 50pcs per tube.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
